3.5 Bar Fuel Pressure Regulator for 1991-2003 BMW E31 E34 E36 E38 E39 E53 13531436110

𝗣𝗿𝗼𝗱𝘂𝗰𝘁 𝗗𝗲𝘁𝗮𝗶𝗹𝘀

New aftermarket fuel-pressure regulator for select gasoline-powered BMW vehicles. This mechanical regulator maintains the specified fuel-rail pressure so the injectors receive a consistent fuel supply under changing engine operating conditions.

Designed as a direct replacement for BMW applications requiring OE reference 13531436110 and a 3.5-bar pressure specification.

𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀

• Product type: Fuel-pressure regulator
• Manufacturer part number: 13432134
• Pressure rating: 3.5 bar
• Approximate pressure: 50.8–51 PSI
• Adjustment type: Non-adjustable
• Fuel type: Gasoline
• Fitment type: Direct replacement
• Performance part: No
• Universal fitment: No
• Quantity: One regulator
• Condition: New

𝗢𝗘 𝗣𝗮𝗿𝘁 𝗡𝘂𝗯𝗲𝗿

• 13531436110
• 13 53 1 436 110
• 13-53-1-436-110

𝗦𝘂𝗽𝗲𝗿𝘀𝗲𝗱𝗲𝗱 𝗕𝗠𝗪 𝗡𝘂𝗺𝗯𝗲𝗿𝘀

• 13531726385
• 13 53 1 726 385
• 13531731615
• 13 53 1 731 615

𝗔𝗳𝘁𝗲𝗿𝗺𝗮𝗿𝗸𝗲𝘁 𝗖𝗿𝗼𝘀𝘀-𝗥𝗲𝗳𝗲𝗿𝗲𝗻𝗰𝗲𝘀

• Standard Motor Products PR293
• Bosch 0280160597
• Bosch 0 280 160 597
• Beck/Arnley 1580724
• Beck/Arnley 1581526
• Beck/Arnley 1591013
• Intermotor 22890
• Additional references: 143839, 219658, 800405 and 2173326

Cross-reference numbers are supplied for identification. Verify specifications and vehicle application before substituting another brand.

𝗩𝗲𝗿𝗶𝗳𝗶𝗲𝗱 𝗕𝗠𝗪 𝗔𝗽𝗽𝗹𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀

BMW 3 Series — E36:

• 1992–1995 BMW 325i
• 1991/1992–1995 BMW 325is
• Select 1998–1999 BMW 323i and 323is E36 models
• Select 1996–1999 BMW 328i and 328is E36 models
• Select 1995–1999 BMW M3 models, depending on production date and engine

BMW 5 Series — E34:

• 1991–1995 BMW 525i
• 1993 BMW 525i Touring
• 1994–1995 BMW 530i
• 1994–1995 BMW 540i
• Select 1991–1993 BMW M5 applications

BMW 5 Series — E39:

• 2001–2003 BMW 525i
• 1997–2000 BMW 528i
• 2001–2003 BMW 530i
• 1997–2003 BMW 540i

BMW 7 Series — E32 and E38:

• 1993–1995 BMW 740i — E32
• 1993–1995 BMW 740iL — E32
• 1997–2001 BMW 740i — E38
• 1996–2001 BMW 740iL — E38
• Select 750i and 750iL V12 applications

BMW 8 Series — E31:

• 1994–1997 BMW 840Ci
• Select BMW 850i and 850Ci V12 applications

BMW X5 — E53:

• Select 2000–March 2002 BMW X5 3.0i
• Select 2000–March 2002 BMW X5 4.4i
• Select 2002 BMW X5 4.6is through March 2002

BMW Z3 — E36/7 and E36/8:

• Select Z3 2.8 models
• Select Z3 M Roadster and M Coupe models

𝗜𝗺𝗽𝗼𝗿𝘁𝗮𝗻𝘁 𝗙𝗶𝘁𝗺𝗲𝗻𝘁 𝗡𝗼𝘁𝗲𝘀

BMW used different fuel systems within the same model and model year. Fitment must be confirmed using the OE number, engine, chassis, and production date.

• Some applications changed regulators during the model year
• Certain E53 X5 applications require a production-date check
• Later vehicles may use a regulator incorporated into the fuel filter
• E46 models should not be assumed compatible solely because the vehicle is called a 323i or 328i
• V12 engines may use more than one regulator; verify the quantity required
• Diesel applications are not compatible
• This is a 3.5-bar regulator and must not replace a 3.0-bar or differently rated component

VIN verification is strongly recommended.

𝗛𝗼𝘄 𝗧𝗼 𝗩𝗲𝗿𝗶𝗳𝘆 𝗖𝗼𝗺𝗽𝗮𝘁𝗶𝗯𝗶𝗹𝗶𝘁𝘆

Before ordering:

• Locate the number on the original regulator
• Confirm BMW reference 13531436110 or one of its superseded numbers
• Verify that the required pressure is 3.5 bar
• Confirm the vehicle’s chassis and engine code
• Check the vehicle’s production month and year
• Compare the physical shape and connection points with the listing photographs

Do not order using the vehicle model name alone.

𝗖𝗼𝗺𝗺𝗼𝗻 𝗦𝘆𝗺𝗽𝘁𝗼𝗺𝘀 𝗢𝗳 𝗔 𝗙𝗮𝗶𝗹𝗶𝗻𝗴 𝗥𝗲𝗴𝘂𝗹𝗮𝘁𝗼𝗿

• Hard starting or extended cranking
• Rough or unstable idle
• Engine hesitation or poor acceleration
• Rich or lean fuel mixture
• Black exhaust smoke
• Increased fuel consumption
• Fuel odor
• Incorrect fuel-rail pressure
• Failed emissions inspection
• Fuel leakage near the regulator
• Fuel present in the regulator vacuum line

These symptoms can also be caused by a failing fuel pump, clogged filter, leaking injector, vacuum leak, damaged fuel line, or engine-management fault. Test the fuel system before replacing parts.

𝗜𝗻𝘀𝘁𝗮𝗹𝗹𝗮𝘁𝗶𝗼𝗻

Fuel systems can remain pressurized after the engine is switched off. Relieve fuel pressure according to the appropriate BMW service procedure before removing the original regulator.

• Work only in a well-ventilated area
• Keep sparks, flames, cigarettes, and hot surfaces away
• Disconnect the battery when specified by the service procedure
• Inspect the regulator seat and retaining hardware
• Use new seals or O-rings where required
• Lubricate replacement seals only with an approved product
• Check carefully for fuel leaks after installation

Professional installation is recommended. Improper installation can cause fuel leakage, fire, engine damage, or an incorrect air/fuel mixture.

𝗣𝗮𝗰𝗸𝗮𝗴𝗲 𝗜𝗻𝗰𝗹𝘂𝗱𝗲𝘀

• One 3.5-bar fuel-pressure regulator

𝗡𝗼𝘁 𝗜𝗻𝗰𝗹𝘂𝗱𝗲𝗱

• Fuel rail
• Fuel pump
• Fuel filter
• Injectors
• Vacuum hose
• Mounting tools
• Additional regulators required by some V12 applications
• Seals or hardware unless specifically shown in the listing photographs

Please confirm OE number 13531436110, the 3.5-bar pressure rating, engine, chassis, and production date before purchasing.
