Car Aux-in iPod Adapter MP3 Player Radio Interface for Honda Accord Civic Odyssey Fit
- Item type: Cables, adapters & sockets
- Voltage input: DC 12V
- Signal-to-noise: 95DB
- Max. current: 600mA
- Frequency response: 20HZ-20KHZ
- Working temperature: -10-80 Celsius degree
- Total Harmonic Distortion:0.01%
- Package size: 15 * 10 * 4cm
- Package weight: Approx. 136g
1. Best sound quality from High quality Power amplifier chip and by using the CD changer port connection
3. Plays MP3 and WMA files
4. Plug & play installation
5. Be able to connect an external audio source like:
b. Portable DVD-Player
c. Mini Disk-Player
e. iPhone /iPod/iPhone
f. Mobile Phone, such as HTC, Nokia, Samsung etc.
6. Brand New and High Quality
1. Turn off car engine and remove key from ignition, if your radio use a security code,
make sure that you have the code before unplugging the radio.
2. Unmount the radio from the dash and find CD changer port at the back of radio.
3. Plug the IPOD AUX Adapter connector to CD changer port.(For Audi/V.W/Skoda/Seat radio,connect the GND cable to the shield of the radio)
4. For IPOD/Iphone user,connector IPOD/Iphone via IPOD AUX Adapter 30P connector.once the unit is installed just power on the car radio and ipod,you can Press CD button,then you can enjoy the IPOD Music ,keep Ipod changed and ready to go.
5. For Auxiliary device such as PSP,MD.MP3.mobile etc,connect it with 3.3 Jack cable. It will start play music.
1 * USB Car Adapter
1 * User Manual
