6.5in LA065WV3-SD01 LCD Screen for VW Skoda MIB2 Radio Display Replacement

Product Description

New 6.5-inch replacement LCD display panel for compatible Volkswagen and Škoda factory radio and infotainment systems. This screen replaces displays marked LA065WV3-SD01 and related number formats listed below.

Designed to repair problems such as:

• Cracked or physically damaged LCD
• Blank or dark display
• Lines, blotches or distorted images
• Faded or low-contrast picture
• Other LCD-panel failures

This listing is for the internal replacement LCD panel—not a complete radio, infotainment unit or dashboard display assembly.

Product Details

• Display size: 6.5 inches
• Display type: TFT LCD
• Resolution: 800 × 480 pixels
• Primary part number: LA065WV3-SD01
• Condition: New
• Brand: Unbranded replacement
• Application: Factory automotive radio/infotainment display repair
• Country of manufacture: China
• Professional installation recommended

Compatible Display Numbers

Compare the number printed directly on the original LCD before ordering. Reported compatible references include:

• LA065WV3-SD01
• LA065WV3(SD)(01)
• LA065WV3SD01
• LM1696A01
• LM1696A01-1D
• LM1696A01-1B
• GPM1696A00
• EAT63954701

Vehicle and System Compatibility

This LCD is reported for select Volkswagen and Škoda factory infotainment systems, including certain versions of:

Volkswagen

• Golf
• Jetta
• Passat
• Polo
• Tiguan
• Transporter/Multivan T6.1

Škoda

• Fabia III
• Rapid
• Select other models equipped with the matching 6.5-inch factory display

Reported compatible radio/display assemblies include:

• Škoda units numbered 5JA 035 871 C
• Škoda units numbered 5JA 035 871 D
• Certain Discover Media/MIB2 display assemblies

Compatibility is determined by the LCD number and connector configuration—not by vehicle model alone. Multiple display manufacturers and revisions may have been installed within the same year and model.

Important Compatibility Notice

Before ordering, disassemble or inspect the original unit and confirm:

• Original LCD is marked LA065WV3-SD01
• Screen measures 6.5 inches
• Resolution and image orientation match
• Ribbon-cable quantity, position and contact count match
• Connector locations match the listing photographs
• Backlight and mounting points are identical
• The separate touch panel, if reused, is undamaged

Similar-looking screens may use different firmware, ribbon cables or image orientation. Installing an incompatible revision can result in an upside-down or mirrored image, reversed touch operation, incorrect colors or no display.

Installation

Installation requires disassembly of the factory radio/display assembly and careful handling of delicate ribbon cables. Professional installation by an automotive-electronics or radio-repair technician is strongly recommended.

Disconnect vehicle power before removing the radio. Avoid touching the LCD contacts and use appropriate anti-static precautions. Damage caused during installation is generally not considered a product defect.

Package Includes

• One 6.5-inch LA065WV3-SD01-compatible LCD panel

Radio chassis, control board, bezel, touch digitizer, cables, tools and installation service are not included unless explicitly shown and stated otherwise.
