2013-14 Hyundai Sonata Radio Navigation Control Panel CD Player OEM 96560-3q706

Product Description

Genuine OEM Hyundai navigation radio/head unit for select 2013–2014 Hyundai Sonata models equipped with the factory navigation system and premium externally amplified audio.

This factory unit integrates the navigation display, AM/FM and satellite-capable radio, CD/MP3 playback, Bluetooth connectivity, telematics, and factory USB/AUX operation. It is intended as a replacement for a matching original unit, not as a plug-and-play navigation upgrade for a lesser-equipped vehicle.

The item is used and may display ordinary scratches, scuffs, or other cosmetic wear. Review all listing photos for its exact condition and included components.

Product Details

• Brand: Hyundai
• Type: AVN navigation radio/head unit
• Condition: Used
• Installation location: Front/center dashboard
• Fitment type: Direct replacement
• Navigation: Factory GPS navigation
• Audio: AM/FM, satellite-capable radio and CD/MP3 player
• Connectivity: Bluetooth and factory USB/AUX integration
• Audio configuration: Premium speakers with external JBL amplifier
• Factory option code referenced by interchange sources: 9611NC
• Seller-provided warranty: 30 days
• Universal fitment: No

OEM and Interchange Numbers

• 96560-3Q706
• 965603Q706
• 96560-3Q706-FLT
• 965603Q706FLT
• Hollander interchange: 638-74093

Hyundai’s remanufactured cross-reference identifies 96560-3Q706-FLT as the corresponding service/remanufactured version of the original AVN head unit. Hyundai remanufactured cross-reference

Researched Compatibility

The most strongly documented application is:

• 2013 Hyundai Sonata
• 2014 Hyundai Sonata, depending on production date and original equipment
• Non-hybrid sedan
• Factory navigation
• Premium/Infinity speaker system
• External JBL amplifier
• Factory USB and auxiliary inputs

Hyundai’s catalog assigns this head unit to vehicles produced approximately August 2012 through May 2014, including the 2014 model-year package. Interchange sources describe it as the navigation receiver for the factory premium Infinity system, often identified as a nine-speaker configuration. Hyundai parts catalog, radio configuration reference

Potential trims include GLS, SE, Limited, 2.0T, and 2.0T Limited only when originally fitted with the required navigation and premium amplified audio configuration.

Listing-Year Correction

The existing listing title states 2012–2015, but that range is too broad:

• Earlier 2012 vehicles commonly use different revisions, including 96560-3Q705.
• The redesigned 2015 Sonata uses a different dashboard and electronics platform.
• Available catalog evidence supports approximately late-2012 production through May 2014, primarily covering the 2013–2014 model years.

The recommended listing title should therefore use 2013–2014, with exact compatibility determined by the original radio number and VIN.

Important Compatibility Notice

This radio is highly configuration-specific. It is not confirmed for:

• 2015 Hyundai Sonata
• Sonata Hybrid models
• Vehicles without factory navigation
• Vehicles with the standard, non-premium audio system
• Vehicles using a different amplifier or speaker configuration

A visually identical radio may have different software, connectors, amplifier communication, or vehicle data protocols. Match 96560-3Q706 exactly whenever possible and compare all rear connectors, mounting points, and faceplate features.

Installation Information

Professional installation is recommended. The replacement may require initialization, vehicle-specific setup, or programming. Bluetooth devices and saved settings will need to be paired or configured again. The navigation database may also be outdated and could require a separately purchased update.

Before replacing the radio, diagnose the factory amplifier, wiring, antennas, display, and power supplies because faults elsewhere can produce similar symptoms.

Package Includes

• One OEM Hyundai navigation radio/head unit

No amplifier, GPS antenna, wiring harness, mounting hardware, trim panels, map update, satellite-radio subscription, security code, or additional accessories are included unless clearly shown in the listing photos

Fitment and compatibility

Application reference: 2013-14 Hyundai Sonata Radio Navigation Control Panel CD Player OEM 96560-3q706

Fitment can vary by production date, trim, drivetrain, factory options, connector style and installed equipment. Before ordering, compare the original component, mounting points, electrical connections and specifications with the listing photographs and details.

Part number information

Part number / catalog reference: 96560-3Q706

Part numbers may have supersessions or regional variations. Match at least one reference number and the physical configuration to the original part whenever possible.

Package and installation notes

Quantity is one product unless the title, variant selection or photographs clearly state otherwise. Professional installation is recommended for electrical, safety-related and drivetrain components.
