Genuine VW ESP OFF Traction Control Switch Golf Mk5 Mk6 Jetta Caddy 5K0927117

$ 29.95

Replace a worn, damaged, missing, or inoperative factory ESP traction-control button with this genuine-style Volkswagen console switch.

The switch installs in the original center-console switch position and allows the driver to request reduced or deactivated Electronic Stability Program intervention. Exact operation depends on the vehicle’s factory ABS/ESP system and programming.

Product details

Product type: ESP OFF / traction-control switch
Installation location: Center-console switch panel
Color: Black
Material: Plastic and metal
Approximate length: 48.5 mm
Approximate width: 22.5 mm
Approximate height: 12.5 mm
Approximate weight: 20 g
Illuminated factory-style symbol
Direct replacement when the housing, connector, and part number match

Part numbers

1KD 927 117
1K0 927 117
5K0 927 117
5KD 927 117
1K0 927 117 D
5K0 927 117 REH

REH is the Volkswagen color code commonly used for the satin-black version. Part-number suffixes may vary according to production date and market.

Compatibility

Compatible with selected ESP-equipped Volkswagen vehicles using this switch style:

Volkswagen Golf Mk5 / Type 1K — approximately 2004–2009
Volkswagen GTI Mk5 — approximately 2006–2009
Volkswagen Golf Mk6 / Type 5K — approximately 2009–2013
Volkswagen GTI Mk6 — approximately 2010–2013
Volkswagen Golf Mk6 Estate / Variant / SportWagen — approximately 2010–2014
Volkswagen Golf Plus / Type 5M — selected years
Volkswagen Golf Cabriolet — approximately 2012–2015
Volkswagen Jetta Mk5 / Type 1K — approximately 2005–2010
Volkswagen Vento Mk5 — approximately 2005–2010
Volkswagen Eos / Type 1F — approximately 2006–2014
Volkswagen Caddy Mk3 / Type 2K — approximately 2004–2014
Volkswagen Touran Mk1 / Type 1T — approximately 2007–2010
Volkswagen Scirocco Mk3 / Type 13 — approximately 2009–2014

Model years are provided as a general guide. Volkswagen used different switch versions depending on the vehicle’s production date, market, equipment, and center-console layout.

Important compatibility notes

The vehicle must be equipped with a compatible factory ESP system.
Match the part number, electrical connector, mounting tabs, button symbol, and console position with the original switch.
Some early vehicles use the 1K0 version, while later vehicles may require the 5K0 version.
A production change occurred on certain Golf Mk6 applications around May or June 2010.
This switch may not fit every vehicle within the listed model-year range.
Not intended for vehicles that use an ASR OFF, ESC, MODE, or differently shaped switch.
Replacing an existing compatible switch normally does not require coding.
Retrofitting an ESP OFF button into a vehicle that did not originally have one may require additional wiring and control-module coding. This switch alone is not a complete retrofit kit.

Function

Pressing the button sends a request to the vehicle’s ABS/ESP control system. Depending on the vehicle and software configuration, it may reduce traction-control intervention, disable ASR, place the stability-control system in a sport mode, or partially deactivate ESP. Many vehicles automatically restore normal ESP operation when the ignition is restarted.

Condition

New replacement switch. Please review all photographs and compare the connector and mounting points with your original part before ordering.

Package contents

One ESP OFF traction-control switch

Wiring, connectors, console trim, control modules, and installation tools are not included.

Installation

The switch clips into the factory console switch panel. Carefully remove the surrounding trim, disconnect the original switch, connect the replacement, and reinstall the trim. Professional installation is recommended if you are unfamiliar with interior trim removal or automotive electrical systems.
