OBC MID Pixel Repair Kit for 1989-1999 BMW E31 E36

Product Details

Restore missing or intermittent pixels in compatible BMW E36 11-button On-Board Computers and selected E31 Multi-Information Displays by replacing the failed internal ribbon connection. This is a repair kit, not a complete display.

• Condition: New repair components
• Designed for faded, fragmented or temperature-sensitive display connections

Fitment and Compatibility

• 1992-1999 BMW E36 3 Series 318, 323, 325, 328 and M3 with the matching 11-button OBC
• 1989-1999 BMW E31 8 Series 840 and 850 with the matching MID construction

For the exact 11-button OBC or E31 MID design shown. These units are not universally interchangeable; compare the LCD, housing and ribbon geometry before ordering.

Part Number Information

This aftermarket repair kit has no separate BMW OE part number. Compatibility is determined by the display type and ribbon layout.

Package Contents

• One replacement pixel ribbon cable
• One 40W bonding iron
• One copper T-tip
• One heat-resistant applicator pad

Installation Notes

Installation requires unit disassembly, removal of the original bond, thorough contact cleaning, precise cable alignment, and controlled heat and pressure. Written instructions are not included. Incorrect heat, alignment or pressure can permanently damage the LCD or circuit board; experienced electronic repair is strongly recommended.
